Warning:
Soldering this LED kit is difficult and requires a good understanding of soldering. No replacements will be sent if you damage the kit!
Looking for a more tactile button feel with LEDs? Then look no further than Cloud Game Store's LED kit which features clicky buttons and adjustable RGB LEDs!
Features:
4 sets of fixed colors. 1 set of RGB custom colors, can freely combine thousands of colors. 1 set of scrolling effects, the scrolling effects are automatically mixed by the program. The last button clicks on the mode.
Brightness adjustment: Press and hold SELECT, then click up or down to adjust the brightness from 0 to 5 levels. Release the SELECT button to save. The self editing mode and button click mode do not support brightness adjustment. The brightness adjustment of the ticker is not obvious.
Mode switching: Hold down the START button and press the up and down keys to switch between 7 modes (release the START button to save).
Adjusting the LEDs:
Region self edited colors: D-pad for zone A, AB for zone B, SELECT START for zone C.
Zone A:
Long press the bottom left button for 3 seconds at the same time to keep the light on in that zone, and turn off the lights in other zones. Release and edit the color of the light in Zone A at this time. Editing method: The up and down buttons control green (G), the left and right buttons control red (R), and the AB button controls blue (B). Press the up button to increase the green brightness, and press the down button to decrease the green brightness. Similarly, A increases the blue brightness, B decreases the blue brightness, press left to increase the red brightness, and press right to decrease the red brightness. RGB reaching balance is white light.
Zone B:
Pressing and holding the A and B keys simultaneously for 3 seconds will keep the light on in that zone and turn off the lights in other zones. At this point, release and edit the color of the B zone light using the same editing method as above.
Zone C:
Press and hold the SELECT and START keys simultaneously for 3 seconds to keep the light on in that zone and turn off the lights in other zones. Release the button to edit the color of the light in Zone C, using the same editing method as above.
4 In button mode, SELECT START becomes a breathing light, and the button pressed will trigger brightness enhancement. The color of the button mode light is the color that calls the player's custom mode. When the brightness of the button light is level 2 or level 3. You can turn off the lights and use button mode.
